摘要:近年来, BIM技术在国内建筑行业高速发展, 作为BIM技术应用的代表性软件Revit, 能够实现建筑、结构、施工、设备等多专业的协同设计, 在建筑设计领域得到了广泛的应用。而限于Revit结构分析目前尚不能很好地适应我国规范要求, 结构专业在整个三维信息链中成了孤岛, 导致十年来国内大量结构计算模型无法协同应用。PKPM结构分析软件与国家规范紧密结合, 在建筑结构设计领域得到了广泛的运用, 因此开发PKPM与Revit双向数据接口软件意义重大。本文在Revit平台下开发了PKPM与Revit双向数据接口软件, 并详细介绍了PKPM和Revit接口软件开发过程中关键问题的解决方案。

Abstract: In recent years, BIM technology develops rapidly in the construction industry.As the representative software of the application of BIM technology, Revit can realize collaborative design of architecture, structure, construction, and MEP, and has been widely used in building design field. However, Revit does not meet the building code well in our country currently, so the structure analysis become a lonely island in the entire three-dimensional model information chain, resulting in a large number of domestic structural model can't apply collaborative design in last decade. PKPM structural analysis software combines closely with Chinese building code, and it is widely used. Therefore, it is of great significance to develop a bi-directional data interface software between PKPM and Revit. This article develops a bi-directional data interface software between PKPM and Revit on the Revit platform, and discusses several key issues in the software, along with the detailed solutions.
